ASME-B16.5 Std ASME Cl150 Blind Flange ASTM B366 N10276 Flange
1.ASTM B 622 UNS N10276 steel pipe ,Other common names: Alloy C276, Hastelloy C, Inconel® C-276 Outer Diameter: 10mm-273.1mmWall Thickness: 1mm to 14mm2 . Other material besides Uns N10276 seamless steel pipe we can do : Incoloy800/800H/800HT(UNS N08800/N08810/N08811),Incoloy825(UNS N088......
Send Inquiry
Product Description
1.ASTM B 622 UNS N10276 steel pipe ,
Other common names: Alloy C276, Hastelloy C, Inconel® C-276
Outer Diameter: 10mm-273.1mm
Wall Thickness: 1mm to 14mm
2 . Other material besides Uns N10276 seamless steel pipe we can do :
Incoloy800/800H/800HT(UNS N08800/N08810/N08811),
Incoloy825(UNS N08825/2.4858),Inconel600/601/625(UNS N06600/N06601/N06625),Inconel725(N07725)
Incoloy901/925/926(N09901/N08925/N08926),GH3030(80Ni20Cr),Monel400(N04400/2.4360),
Nickel200(N02200/2.4060),Hastelloy C-276(N10276/2.4819)
Alloy C276 Pipes
3 .Chemipetro supplies C276 steel pipes in the following Product Forms:
Seamless pipe to ASTM B622 and ASME SB622
Welded pipe to ASTM B619 and ASME SB619
Flanges to ASTM B564 and ASME SB564
Fittings to ASTM B366 and ASME SB366
Bar to ASTM B574 and ASME SB574
Plate to ASTM B575 and ASME SB575
4 .What are the characteristics of Hastelloy C276 steel pipe?
Excellent corrosion resistance in reducing environments
Exceptional resistance to strong solutions of oxidizing salts, such as ferric and cupric chlorides
High nickel and molybdenum contents providing good corrosion resistance in reducing environments
Low carbon content which minimizes grain-boundary carbide precipitation during welding to maintain resistance to corrosion in heat-affected zones of welded joints
Resistance to localized corrosion such as pitting and stress-corrosion cracking
One of few materials to withstand the corrosive effects of wet chlorine gas, hypochlorite and chlorine dioxide
C276 Nickel Alloy Pipe Chemical Composition, %
Other common names: Alloy C276, Hastelloy C, Inconel® C-276
Outer Diameter: 10mm-273.1mm
Wall Thickness: 1mm to 14mm
2 . Other material besides Uns N10276 seamless steel pipe we can do :
Incoloy800/800H/800HT(UNS N08800/N08810/N08811),
Incoloy825(UNS N08825/2.4858),Inconel600/601/625(UNS N06600/N06601/N06625),Inconel725(N07725)
Incoloy901/925/926(N09901/N08925/N08926),GH3030(80Ni20Cr),Monel400(N04400/2.4360),
Nickel200(N02200/2.4060),Hastelloy C-276(N10276/2.4819)
Alloy C276 Pipes
3 .Chemipetro supplies C276 steel pipes in the following Product Forms:
Seamless pipe to ASTM B622 and ASME SB622
Welded pipe to ASTM B619 and ASME SB619
Flanges to ASTM B564 and ASME SB564
Fittings to ASTM B366 and ASME SB366
Bar to ASTM B574 and ASME SB574
Plate to ASTM B575 and ASME SB575
4 .What are the characteristics of Hastelloy C276 steel pipe?
Excellent corrosion resistance in reducing environments
Exceptional resistance to strong solutions of oxidizing salts, such as ferric and cupric chlorides
High nickel and molybdenum contents providing good corrosion resistance in reducing environments
Low carbon content which minimizes grain-boundary carbide precipitation during welding to maintain resistance to corrosion in heat-affected zones of welded joints
Resistance to localized corrosion such as pitting and stress-corrosion cracking
One of few materials to withstand the corrosive effects of wet chlorine gas, hypochlorite and chlorine dioxide
C276 Nickel Alloy Pipe Chemical Composition, %
| Ni | Mo | Cr | Fe | W | Co | Mn | C |
|---|---|---|---|---|---|---|---|
| Remainder | 15.0-17.0 | 14.5-16.5 | 4.0-7.0 | 3.0-4.5 | 2.5 max | 1.0 max | .01 max |
| V | P | S | Si | ||||
| .35 max | .04 max |
GUANGZHOU KINGMETAL STEEL INDUSTRY CO., LTD. is an Industry Group Company. It is a professional company in designing, producing and selling steel pipe, pipe fittings, flanges, valves . We have our own big factories with modern machine line to make high quality products, which is mainly to be exported to oversea markets.
