              Wing Union Fig. 1003 Hammer Union Standard Service
              • Wing Union Fig. 1003 Hammer Union Standard ServiceWing Union Fig. 1003 Hammer Union Standard Service
              • Wing Union Fig. 1003 Hammer Union Standard ServiceWing Union Fig. 1003 Hammer Union Standard Service
              • Wing Union Fig. 1003 Hammer Union Standard ServiceWing Union Fig. 1003 Hammer Union Standard Service
              • Wing Union Fig. 1003 Hammer Union Standard ServiceWing Union Fig. 1003 Hammer Union Standard Service

              Wing Union Fig. 1003 Hammer Union Standard Service

              Weco style Wing Unions / Hammer UnionsBETTER Wing Unions are widely used in the fluid or mud manifolds, Cementing and choke-and kill lines; it was divided by union color code, to use for lower-pressure, middle-pressure and high-pressure standard trim or H2S trim. We also manufacture compatible Hamme......

              Send Inquiry

              Product Description

              Wing Union Fig. 1003 Hammer Union Standard Service
              Weco style Wing               Unions / Hammer Unions

              BETTER Wing Unions are widely used in the fluid or mud manifolds, Cementing and choke-and kill lines; it was divided by union color code, to use for lower-pressure, middle-pressure and high-pressure standard trim or H2S trim. We also manufacture compatible Hammer Union Seals (Lip Seal), O-ring, Lip seal rings, stainless steel backed seal rings, and brass backed seal rings for Weco Wing Union.

              Features
              • Adopted high strength alloy steel/carbon steel appropriate to specific pressure rating, strict heat treatment technique, rigid quality control as per API Spec 16C ;
              • Equivalent to FMC WECO style Hammer Union with identical size to ensure easy replacement;
              • API Standard LP/NPT, Tubing threaded, and butt-weld end connection available;
              • Complete line of standard service and sour gas wing unions in size from 1"-12" with working pressure up to 20000psi, Sour service conform to NACE specification;
              • Quality and full style of hammer union seals can be provided in Buna-N, Viton, and Buna-N/Viton with a brass ring, Buna-N/Viton with a stainless steel ring, and Teflon. There are 80 Nitrile, 80 Viton, 90 Viton or upon request.
              • The same figure number, size, and pressure rating are interchangeable, making it easy to match male and female subs that are frequently made-up and broken-out.

              Weco style wing unions are the most complete line of sour gas pipe connections available, ranging in size from 2" to 6" with cold working pressure to 15000psi. All weco unions are color coded. Material meet NACE MR-01-75, ASTM and AISI standard.

              Features and Benefits
              Positive sealing designs, Fast make-up and break-out, End connections are butt-welded and threaded for option

              Below is for sour gas application
               Fig.2202 Butt WeldFig.1502 Butt Welded SCH.XXHFig.1003 Butt Weld with Misaligning Union SCH.XXH
              Size(INCH)2"3"23434
              Completion union3235746325215932487003235505325688132572273261476
              Nut3233306325628132379533237773325167332572323261479
              Male Sub3235747325215732487013235536325687932672253261478
              Female Sub3235748325215832487023237771325688032572263261477
              Viton seal ring3233069325167132324343232646325167232310573233034

               Fig.1002 Butt Welded SCH.XXH
              Size (INCH)23456
              Completion union325369432404283254936P508629P508519
              Nut325369332409143241596P508666P508518
              Male Sub3253267324160532549383257700P508283
              Female Sub3253268324818332549373257701P508284
              Viton seal ring32324343232646323265432323873255971



               Fig.602 Butt Weld SCH.XXHFig.602 Butt Weld SCH.160Fig.602 Butt Weld SCH.80Fig.602 Butt Weld SCH.40
              Size (INCH)234234234234
              Completion unionP509453P509454P509455P509450P509451P509452P509447P509448P509449P509444P509445P509446
              NutP508207P508214P508222P508207P508214P508222P508207P508214P508222P508207P508214P508222
              Male SubP508210P508217P508225P508209P508216P508224P508208P508215P508223P509462P509463P509464
              Female Sub w/seal ringP509426P509427P509428P509423P509424P509425P509412P509414P509415P509465P509466P509467
              Viton seal ring323243432326463232654323243432326463232654323243432326463232654323243432326463232654

               Fig.206 Butt Welded SCH.80Fig.206 Butt Welded SCH.40
              Size (INCH)23462346
              Completion unionP509432P509433P509440P509441P509429P509430P509431P509442
              NutP508070P508073P5080763212866P508070P508073P5080763212866
              Male Sub W/o RingP509408P509409P509410P509411P509456P509457P509458P509422
              Female SubP508072P508075P5080783237328P509459P509460P5094613206887
              Viton seal ring3231045323104932596483232388832310453231049325964832323888

              Below is for standard service
              Fig.100Fig.200
              22.5346811.251.522.53
              320060932006103200611320061232007953200796320082932009603200773320077832008993200782
              Fig.206
              11.251.522.5346810
              3207627320763332076363207281320727832030483205449320252132025523202566
              Fig.207Fig.211
              34681011.522.534
              32079063207907320790832079813207982320536932053813205343320538832053633205355
              Fig.400
              22.5345.5 OD67 OD81012
              3200291320029032002923200337320634732021793204333320206032067473201578
              FIG.600Fig.602
              11.523411.251.5234
              32018263200433320043432004363200437320237732024343202428320238232024163202399
              Fig.1002Fig.1003
              11.251.522.52.5 EUE34234
              32056813205675320566532031323205626320692732055653205533320851932199283219932
              Fig.1502Fig.2002Fig.2202
              11.522.5342323
              3254059325405732015703203088320751032529263222761324591132357463257994
