Robust Clamp with Solid Nut 24*1.5/0.8 68 mm to 130 mm

Product Description

R0bust Clamp With S0lid Nut

Bandwidth*Thickness (mm)	Pr0duct C0de				Size(mm)	Package		cart0n Size (cm)	G.W./Ctn (kg)	Screw	T0rque (N.m)
Bandwidth*Thickness (mm)	Pr0duct C0de				Size(mm)	pcs/bag	pcs/ctn	cart0n Size (cm)	G.W./Ctn (kg)	Screw	T0rque (N.m)
18*0.6/0.6	RG19	RS19	RSS19	RSS519	17-19	10	250	382713	10.75	M5	≥5
	RG22	RS22	RSS22	RSS522	20-22	10	250	382713	10.85	M5	≥5
	RG25	RS25	RSS25	RSS525	23-25	10	250	382715	11.10	M5	≥5
	RG28	RS28	RSS28	RSS528	26-28	10	250	382715	11.39	M5	≥10
22*1.2/0.8	RG31	RS31	RSS31	RSS531	29-31	10	200	382717	12.10	M6	≥10
	RG35	RS35	RSS35	RSS535	32-35	10	200	382719	12.60	M6	≥10
	RG39	RS39	RSS39	RSS539	36-39	10	200	382721	13.14	M6	≥10
	RG41	RS41	RSS41	RSS541	39-41	10	200	382724	13.19	M6	≥10
	RG43	RS43	RSS43	RSS543	40-43	10	200	382724	17.71	M6	≥10
26*1.7/1.0	RG47	RS47	RSS47	RSS547	44-47	10	200	382727	18.14	M6	≥10
	RG51	RS51	RSS51	RSS551	48-51	10	200	382727	18.83	M6	≥10
	RG55	RS55	RSS55	RSS555	52-55	10	200	382729	19.40	M6	≥10
	RG59	RS59	RSS59	RSS559	56-59	10	100	382717	10.01	M6	≥10
	RG63	RS63	RSS63	RSS563	60-63	10	100	382717	10.21	M6	≥10
	RG67	RS67	RSS67	RSS567	64-67	10	100	382727	16.32	M8	≥20
24*1.5/0.8	RG73	RS73	RSS73	RSS573	68-73	10	100	382727	16.77	M8	≥20
	RG79	RS79	RSS79	RSS579	74-79	10	100	382734	17.10	M8	≥20
	RG85	RS85	RSS85	RSS585	80-85	10	100	382735	17.65	M8	≥20
	RG91	RS91	RSS91	RSS591	86-91	10	100	382736	18.25	M8	≥20
	RG97	RS97	RSS97	RSS597	92-97	10	100	403735	19.32	M8	≥20
	RG103	RS103	RSS103	RSS5103	98-103	10	100	403735	20.10	M8	≥20
	RG112	RS112	RSS112	RSS5112	104-112	10	100	403740	20.50	M8	≥20
	RG121	RS121	RSS121	RSS5121	113-121	10	100	403740	21.40	M8	≥20
	RG130	RS130	RSS130	RSS5130	122-130	5	50	403730	15.17	M10	≥35
26*1.7/1.0	RG139	RS139	RSS139	RSS5139	131-139	5	50	403730	15.33	M10	≥35
	RG148	RS148	RSS148	RSS5148	140-148	5	50	403735	16.66	M10	≥35
	RG161	RS161	RSS161	RSS5161	149-161	5	25	403735	17.41	M10	≥35
	RG174	RS174	RSS174	RSS5174	162-174	5	25	382734	9.16	M10	≥35
	RG187	RS187	RSS187	RSS5187	175-187	5	25	403728	9.57	M10	≥35
	RG200	RS200	RSS200	RSS5200	188-200	5	25	403728	9.86	M10	≥35
	RG213	RS213	RSS213	RSS5213	201-203	5	25	403730	10.69	M10	≥35
	RG226	RS226	RSS226	RSS5226	214-226	5	25	403730	10.91	M10	≥35
	RG239	RS239	RSS239	RSS5239	227-239	5	25	403730	11.52	M10	≥35
	RG252	RS252	RSS252	RSS5252	240-252	5	25	403731	12.60	M10	≥35
